Replacement for floodlights − with halogen lamps
− Outdoor use (IP66)
− D-sign according to EN 60598-2-24 for fire-risk commercial unit, e.g. by accumulation of dust
− Public areas
− Building facades
− Construction areas
− Parking
− Gardens and balconies
− Breather membrane to optimize air exchange, without compromising IP protection
− Highly versatile due to selectable power steps (Multi Lumen) on the housing
− Robust cable gland with integrated waterstop function
− Safe and very uniform illumination, due to frosted and tempered glass diffuser
− Bright, robust and durable
− Energy savings of up to 90 % compared to halogen lamp floodlights
− No upper light output ratio (ULOR 0%) when mounted at 0° tilt
− High luminous efficacy: up to 145 lm/W
− Type of protection: IP66
− Pre-installed, flexible 1 m cable (H05RN-F), wrapped 3 x 1.0 mm² single wires
− Reflector-based, symmetric light distribution with 100° x 100° beam angle
− Mounting bracket with 30° angle and wide rotation area
Nominal wattage: 41 W / 27 W
Nominal voltage: 220…240 V
Mains frequency: 50…60 Hz
Nominal current: 185/130 mA
Inrush current: 14.85 A
Inrush current time T h50: 33.6 μs
Max. number of luminaires per miniature circuit breaker B16: 50
Max. number of luminaires per miniature circuit breaker C10: 40
Max. number of luminaires per miniature circuit breaker C16: 64
Power factor λ: > 0.90
Total harmonic distortion: < 20 %
Protection class: I
Surge capability (L-N): 2 kV
Surge capability (L/N-Ground): 4 kV
Operating mode: Integrated LED driver
Luminous flux: 6000 lm / 4000 lm
Luminous efficacy: 145 lm/W
Color temperature: 4000 K
Light color (designation): Cool White
Color rendering index Ra: 80
Standard deviation of color matching: 5 sdcm
Stroboscope effect metric (SVM): ≤0.9
Photobiological safety group acc. to EN62778: RG1
Photobiological safety group acc. to EN62471: RG1
Beam angle: 100 ° x 100 °
