− Replacement for spotlights − with halogen lamps
- Outdoor use (IP65)
D-mark according to EN 60598-2-24 for fire-hazardous operating areas, e.g. due to dust accumulation
- Public spaces
- Facades of buildings
- Construction areas
- Parking
- Gardens and balconies
− Demand optimized lighting thanks to flexible and programmable sensor
− Easy adjustment of sensor range, daylight detection, hold time and dimming function
− Always-on override, activated via special mains voltage switching pattern
− Breathable membrane for optimum air exchange, without compromising IP protection
− Highly versatile thanks to selectable power steps (Multi Lumen) on the housing
− Robust cable gland with integrated water stop function
− Safe and very even lighting thanks to the diffuser made of frosted and tempered glass
- Clear, robust and durable
− Energy savings up to 90% compared to halogen lamp spotlights
− No higher light output (ULOR 0%) when mounted at an angle of 0°
− Flexible motion and daylight sensor
− Sensor with 350° pan and 200° tilt
− High light output: up to 145 lm/W
- Protection type: IP65
− Pre-installed, flexible cable of 1 m (H05RN-F), wound with 3 x 1.0 mm² single wires
− Reflector-based, symmetrical light distribution with a beam angle of 100° x 100°
− Mounting bracket with 30° angle and large rotation area
− Integrated voltage regulator, suitable for 220 - 240 V AC
Nominal power: 41 W / 27 W
Nominal voltage: 220…240 V
Mains frequency: 50…60 Hz
Nominal current: 185/130 mA
Inrush current: 37.96 A
Switch-on current time T h50: 33.8 μs
Maximum number of luminaires per circuit breaker B16: 19
Maximum number of luminaires per circuit breaker C10: 15
Maximum number of luminaires per circuit breaker C16: 25
Power factor λ : > 0.90
Total harmonic distortion: < 20%
Protection class: I
Surge protection (LN): 4 kV
Surge protection (L/N-ground): 6 kV
Operating mode: Integrated LED driver
Luminous flux: 6000 lm / 4000 lm
Luminous Efficiency: 145 lm/W
Color temperature: 4000 K
Light color (designation): Cool white
Color rendering index Ra: 80
Standard deviation of color matching: 5 sdcm
Strobe effect metric (SVM): ≤0.9
Photobiological safety group according to EN62778: RG1
Photobiological safety group according to EN62471: RG1
Beam angle: 100° x 100°
