− Outdoor use (IP66)
− M-, C- and P-class roads acc. to EN 13201
− Parking
− Public areas
− Industry
− Durable design and highest quality component selection for long lasting performance
− Quick and easy wiring, due to tool-free housing opening and push button terminal
− High light uniformity
− 3 light colors available, perfectly suited to illuminate highly diverse surroundings
− No upper light output ratio (ULOR 0%) when mounted at 0° tilt
− Automatic mains disconnection when opening the housing
− 5 years guarantee
− Light distributions optimized for streets of similar width to the pole height
− Very long lifetime (L90/B10): Up to 100,000 h (at 25 °C)
− Spigot for 48-60 mm poles included
− Additional reduction for 42 mm and adapter for 76 mm poles available separately
− Adjustable spigot for both side-entry and post-top installation
− +/- 15° tilt angle adjustment without opening the housing
− High luminous efficacy: − up to 144 lm/W
− Operating temperature: -40...50 °C
− High surge protection: up to 10 kV (L/N-GND)
− Protection class: II
Nominal wattage: 36.00 W
Nominal voltage: 220…240 V
Mains frequency: 50…60 Hz
Nominal current: 160 mA
Inrush current: 26 A
Inrush current time T h50: 180 μs
Max. number of luminaires per miniature circuit breaker B16: 16
Max. number of luminaires per miniature circuit breaker C10: 25
Max. number of luminaires per miniature circuit breaker C16: 32
Power factor λ: > 0.90
Total harmonic distortion: < 10 %
Protection class: II
Operating mode: Integrated LED driver
Luminous flux: 5180 lm
Luminous efficacy: 144 lm/W
Color temperature: 4000 K
Light color (designation): Cool White
Color rendering index Ra: 70
Standard deviation of color matching: < 5 sdcm
Low flicker: Yes
Photobiological safety group acc. to EN62778: RG1
Photobiological safety group acc. to EN62471: RG1
Beam angle: 25 ° x 145 °
